Fujitsu Ceiling Type Design & Technical Manual

¢
Heating capacity (Triple)

Compact cassette type
Model: AUYG24LVLA × 3
AFR
m
3
/h
2,790
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.85 10.32 5.97 10.07 6.09 9.82 6.21 9.57 6.32
-15 -16 16.21 6.75 15.83 6.89 15.44 7.03 15.06 7.17 14.68 7.31
-10 -11 18.89 7.17 18.44 7.32 18.00 7.47 17.55 7.62 17.10 7.77
-5 -7 20.98 7.48 20.48 7.63 19.98 7.79 19.48 7.94 18.99 8.10
0 -2 22.62 7.55 22.08 7.71 21.54 7.87 21.00 8.02 20.47 8.18
5 3 25.56 7.57 24.95 7.73 24.35 7.89 23.73 8.03 23.13 8.19
7 6 25.83 7.58 25.22 7.74 24.60 7.89 23.99 8.05 23.37 8.21
10 8 27.04 7.53 26.39 7.68 25.74 7.84 25.09 7.99 24.46 8.16
15 10 28.06 7.52 27.39 7.67 26.72 7.83 26.05 8.00 25.38 8.11
20 15 25.25 6.57 24.64 6.69 24.04 6.83 23.44 6.98 22.83 7.07
24 18 25.81 6.53 25.19 6.66 24.58 6.80 23.96 6.94 23.35 7.03

Duct type
Model: ARYG24LMLA × 3
AFR
m
3
/h
3,300
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.73 10.32 5.85 10.07 5.97 9.82 6.09 9.57 6.20
-15 -16 16.21 6.62 15.83 6.75 15.44 6.89 15.06 7.03 14.68 7.17
-10 -11 18.89 7.03 18.44 7.17 18.00 7.32 17.55 7.47 17.10 7.61
-5 -7 20.98 7.33 20.48 7.48 19.98 7.63 19.48 7.78 18.99 7.94
0 -2 22.62 7.40 22.08 7.56 21.54 7.71 21.00 7.87 20.47 8.02
5 3 25.56 7.42 24.95 7.58 24.35 7.73 23.73 7.87 23.13 8.02
7 6 25.83 7.43 25.22 7.58 24.60 7.74 23.99 7.89 23.37 8.05
10 8 27.04 7.38 26.39 7.52 25.74 7.69 25.09 7.83 24.46 8.00
15 10 28.06 7.37 27.39 7.52 26.72 7.68 26.05 7.84 25.38 7.95
20 15 25.25 6.43 24.64 6.56 24.04 6.70 23.44 6.84 22.83 6.93
24 18 25.81 6.40 25.19 6.52 24.58 6.67 23.96 6.81 23.35 6.89

Floor/Ceiling type
Model: ABYG24LVTA × 3
AFR
m
3
/h
2,940
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 10.58 5.85 10.32 5.97 10.07 6.09 9.82 6.21 9.57 6.32
-15 -16 16.21 6.75 15.83 6.89 15.44 7.03 15.06 7.17 14.68 7.31
-10 -11 18.89 7.17 18.44 7.32 18.00 7.47 17.55 7.62 17.10 7.77
-5 -7 20.98 7.48 20.48 7.63 19.98 7.79 19.48 7.94 18.99 8.10
0 -2 22.62 7.55 22.08 7.71 21.54 7.87 21.00 8.02 20.47 8.18
5 3 25.56 7.57 24.95 7.73 24.35 7.89 23.73 8.03 23.13 8.19
7 6 25.83 7.58 25.22 7.74 24.60 7.89 23.99 8.05 23.37 8.21
10 8 27.04 7.53 26.39 7.68 25.74 7.84 25.09 7.99 24.46 8.16
15 10 28.06 7.52 27.39 7.67 26.72 7.83 26.05 8.00 25.38 8.11
20 15 25.25 6.57 24.64 6.69 24.04 6.83 23.44 6.98 22.83 7.07
24 18 25.81 6.53 25.19 6.66 24.58 6.80 23.96 6.94 23.35 7.03
- 156 -
6-1. Model: AOYG72LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
