Fujitsu Ceiling Type Design & Technical Manual

¢
Cooling capacity (Triple)

Compact cassette type
Model: AUYG24LVLA × 3
AFR
m
3
/h
2,790
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 12.40 2.94 19.42 12.48 2.99 20.08 13.57 3.01 21.40 13.61 3.04 22.07 14.69 3.05 23.39 14.63 3.09 24.72 15.60 3.11
-10 17.26 12.28 2.95 19.23 12.35 3.00 19.88 13.43 3.01 21.20 13.47 3.04 21.85 14.55 3.06 23.16 14.49 3.09 24.48 15.43 3.11
0 17.10 12.16 3.14 19.05 12.24 3.18 19.69 13.30 3.20 20.99 13.35 3.24 21.64 14.40 3.26 22.95 14.35 3.29 24.24 15.28 3.32
5 17.06 12.13 3.28 19.01 12.20 3.33 19.65 13.27 3.35 20.94 13.30 3.38 21.60 14.37 3.40 22.89 14.32 3.43 24.19 15.25 3.47
10 16.88 12.11 3.68 18.81 12.19 3.74 19.44 13.24 3.76 20.72 13.29 3.80 21.37 14.35 3.82 22.65 14.30 3.86 23.94 15.22 3.90
15 16.40 11.97 3.81 18.25 12.17 3.87 18.89 13.22 3.89 20.12 13.26 3.93 20.74 14.33 3.95 21.99 14.27 3.99 23.23 15.20 4.03
20 16.62 12.08 4.24 18.50 12.29 4.31 19.14 13.35 4.32 20.40 13.39 4.37 21.03 14.47 4.39 22.29 14.41 4.44 23.56 15.35 4.48
25 16.78 12.09 5.03 18.69 12.29 5.11 19.33 13.36 5.13 20.61 13.40 5.19 21.24 14.49 5.21 22.52 14.43 5.26 23.79 15.37 5.31
30 16.45 11.49 5.74 18.33 11.68 5.82 18.96 12.70 5.85 20.19 12.74 5.92 20.82 13.76 5.94 22.07 13.71 6.00 23.32 14.61 6.07
35 15.01 11.23 6.40 16.72 11.48 6.50 17.29 12.49 6.54 18.43 12.52 6.60 19.00 13.53 6.63 20.14 13.47 6.70 21.28 14.35 6.77
40 14.86 10.60 6.06 16.55 10.91 6.14 17.12 11.86 6.19 18.25 11.90 6.24 18.81 12.85 6.27 19.94 12.81 6.34 21.07 13.63 6.41
46 11.84 9.61 5.91 13.19 10.32 5.99 13.63 10.94 6.02 14.52 11.26 6.08 14.98 12.16 6.12 15.89 12.10 6.18 16.78 12.88 6.24

Duct type
Model: ARYG24LMLA × 3
AFR
m
3
/h
3,300
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 12.65 2.87 19.42 12.73 2.92 20.08 13.84 2.93 21.40 13.89 2.96 22.07 14.99 2.97 23.39 14.93 3.01 24.72 15.91 3.04
-10 17.26 12.53 2.88 19.23 12.60 2.92 19.88 13.70 2.93 21.20 13.74 2.96 21.85 14.84 2.98 23.16 14.79 3.01 24.48 15.75 3.04
0 17.10 12.41 3.07 19.05 12.49 3.11 19.69 13.57 3.13 20.99 13.62 3.16 21.64 14.70 3.18 22.95 14.64 3.21 24.24 15.59 3.24
5 17.06 12.38 3.20 19.01 12.45 3.25 19.65 13.54 3.27 20.94 13.57 3.30 21.60 14.66 3.32 22.89 14.61 3.35 24.19 15.56 3.38
10 16.88 12.36 3.59 18.81 12.43 3.65 19.44 13.51 3.67 20.72 13.56 3.71 21.37 14.64 3.73 22.65 14.59 3.76 23.94 15.53 3.81
15 16.40 12.21 3.72 18.25 12.42 3.77 18.89 13.49 3.80 20.12 13.53 3.83 20.74 14.62 3.85 21.99 14.56 3.89 23.23 15.50 3.93
20 16.62 12.33 4.14 18.50 12.53 4.21 19.14 13.63 4.22 20.40 13.67 4.26 21.03 14.77 4.29 22.29 14.71 4.33 23.56 15.66 4.37
25 16.78 12.33 4.91 18.69 12.54 4.98 19.33 13.64 5.01 20.61 13.68 5.06 21.24 14.78 5.08 22.52 14.72 5.13 23.79 15.68 5.18
30 16.45 11.72 5.60 18.33 11.92 5.68 18.96 12.96 5.71 20.19 13.00 5.77 20.82 14.04 5.80 22.07 13.98 5.85 23.32 14.91 5.92
35 15.01 11.45 6.25 16.72 11.72 6.34 17.29 12.74 6.38 18.43 12.78 6.44 19.00 13.80 6.47 20.14 13.74 6.53 21.28 14.64 6.60
40 14.86 10.82 5.91 16.55 11.13 5.99 17.12 12.10 6.04 18.25 12.14 6.09 18.81 13.11 6.12 19.94 13.06 6.18 21.07 13.91 6.25
46 11.84 9.80 5.76 13.19 10.53 5.84 13.63 11.16 5.88 14.52 11.49 5.93 14.98 12.40 5.97 15.89 12.35 6.03 16.78 13.14 6.08

Floor/Ceiling type
Model: ABYG24LVTA × 3
AFR
m
3
/h
2,940
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 12.40 2.94 19.42 12.48 2.99 20.08 13.57 3.01 21.40 13.61 3.04 22.07 14.69 3.05 23.39 14.63 3.09 24.72 15.60 3.11
-10 17.26 12.28 2.95 19.23 12.35 3.00 19.88 13.43 3.01 21.20 13.47 3.04 21.85 14.55 3.06 23.16 14.49 3.09 24.48 15.43 3.11
0 17.10 12.16 3.14 19.05 12.24 3.18 19.69 13.30 3.20 20.99 13.35 3.24 21.64 14.40 3.26 22.95 14.35 3.29 24.24 15.28 3.32
5 17.06 12.13 3.28 19.01 12.20 3.33 19.65 13.27 3.35 20.94 13.30 3.38 21.60 14.37 3.40 22.89 14.32 3.43 24.19 15.25 3.47
10 16.88 12.11 3.68 18.81 12.19 3.74 19.44 13.24 3.76 20.72 13.29 3.80 21.37 14.35 3.82 22.65 14.30 3.86 23.94 15.22 3.90
15 16.40 11.97 3.81 18.25 12.17 3.87 18.89 13.22 3.89 20.12 13.26 3.93 20.74 14.33 3.95 21.99 14.27 3.99 23.23 15.20 4.03
20 16.62 12.08 4.24 18.50 12.29 4.31 19.14 13.35 4.32 20.40 13.39 4.37 21.03 14.47 4.39 22.29 14.41 4.44 23.56 15.35 4.48
25 16.78 12.09 5.03 18.69 12.29 5.11 19.33 13.36 5.13 20.61 13.40 5.19 21.24 14.49 5.21 22.52 14.43 5.26 23.79 15.37 5.31
30 16.45 11.49 5.74 18.33 11.68 5.82 18.96 12.70 5.85 20.19 12.74 5.92 20.82 13.76 5.94 22.07 13.71 6.00 23.32 14.61 6.07
35 15.01 11.23 6.40 16.72 11.48 6.50 17.29 12.49 6.54 18.43 12.52 6.60 19.00 13.53 6.63 20.14 13.47 6.70 21.28 14.35 6.77
40 14.86 10.60 6.06 16.55 10.91 6.14 17.12 11.86 6.19 18.25 11.90 6.24 18.81 12.85 6.27 19.94 12.81 6.34 21.07 13.63 6.41
46 11.84 9.61 5.91 13.19 10.32 5.99 13.63 10.94 6.02 14.52 11.26 6.08 14.98 12.16 6.12 15.89 12.10 6.18 16.78 12.88 6.24
- 155 -
6-1. Model: AOYG72LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
