Fujitsu Ceiling Type Design & Technical Manual

6. Capacity table
6-1. Model: AOYG72LRLA
TC: Total Capacity, SHC: Sensible Heat Capacity, IP: Input Power
¢
Cooling capacity (Twin)

Cassette type
Model: AUYG36LRLE × 2
AFR
m
3
/h
3,600
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 14.10 2.73 19.42 14.19 2.77 20.08 15.43 2.79 21.40 15.49 2.82 22.07 16.71 2.83 23.39 16.65 2.86 24.72 17.74 2.89
-10 17.26 13.96 2.74 19.23 14.05 2.78 19.88 15.28 2.79 21.20 15.32 2.82 21.85 16.55 2.83 23.16 16.48 2.86 24.48 17.56 2.89
0 17.10 13.83 2.91 19.05 13.92 2.95 19.69 15.13 2.97 20.99 15.18 3.00 21.64 16.38 3.02 22.95 16.32 3.05 24.24 17.38 3.08
5 17.06 13.80 3.04 19.01 13.88 3.09 19.65 15.09 3.11 20.94 15.13 3.14 21.60 16.35 3.16 22.89 16.28 3.18 24.19 17.35 3.21
10 16.88 13.77 3.42 18.81 13.86 3.47 19.44 15.06 3.49 20.72 15.12 3.52 21.37 16.32 3.54 22.65 16.27 3.58 23.94 17.32 3.62
15 16.40 13.61 3.53 18.25 13.84 3.59 18.89 15.04 3.61 20.12 15.09 3.64 20.74 16.30 3.66 21.99 16.23 3.70 23.23 17.28 3.74
20 16.62 13.74 3.93 18.50 13.97 4.00 19.14 15.19 4.01 20.40 15.23 4.05 21.03 16.46 4.08 22.29 16.40 4.12 23.56 17.46 4.15
25 16.78 13.75 4.67 18.69 13.98 4.74 19.33 15.20 4.76 20.61 15.25 4.81 21.24 16.48 4.83 22.52 16.41 4.88 23.79 17.48 4.93
30 16.45 13.07 5.33 18.33 13.29 5.40 18.96 14.45 5.43 20.19 14.49 5.49 20.82 15.65 5.51 22.07 15.59 5.56 23.32 16.62 5.63
35 15.01 12.77 5.94 16.72 13.06 6.02 17.29 14.20 6.06 18.43 14.24 6.12 19.00 15.39 6.15 20.14 15.32 6.21 21.28 16.32 6.27
40 14.86 12.06 5.62 16.55 12.41 5.70 17.12 13.49 5.74 18.25 13.53 5.79 18.81 14.62 5.82 19.94 14.57 5.88 21.07 15.51 5.94
46 11.84 10.93 5.48 13.19 11.74 5.55 13.63 12.44 5.59 14.52 12.81 5.64 14.98 13.83 5.68 15.89 13.77 5.73 16.78 14.65 5.78

Duct type
Model: ARYG36LMLE × 2
AFR
m
3
/h
3,800
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 13.04 3.06 19.42 13.12 3.11 20.08 14.26 3.13 21.40 14.32 3.16 22.07 15.45 3.17 23.39 15.39 3.21 24.72 16.40 3.24
-10 17.26 12.91 3.07 19.23 12.99 3.12 19.88 14.12 3.13 21.20 14.16 3.16 21.85 15.30 3.18 23.16 15.24 3.21 24.48 16.23 3.24
0 17.10 12.79 3.27 19.05 12.87 3.31 19.69 13.98 3.33 20.99 14.03 3.36 21.64 15.15 3.38 22.95 15.09 3.42 24.24 16.07 3.45
5 17.06 12.76 3.41 19.01 12.83 3.46 19.65 13.95 3.48 20.94 13.99 3.51 21.60 15.11 3.54 22.89 15.05 3.57 24.19 16.03 3.60
10 16.88 12.73 3.83 18.81 12.81 3.89 19.44 13.93 3.91 20.72 13.98 3.95 21.37 15.09 3.97 22.65 15.04 4.01 23.94 16.01 4.06
15 16.40 12.58 3.96 18.25 12.80 4.02 18.89 13.91 4.05 20.12 13.95 4.08 20.74 15.07 4.11 21.99 15.01 4.14 23.23 15.98 4.19
20 16.62 12.71 4.41 18.50 12.92 4.48 19.14 14.04 4.49 20.40 14.08 4.54 21.03 15.22 4.57 22.29 15.16 4.62 23.56 16.14 4.65
25 16.78 12.71 5.23 18.69 12.93 5.31 19.33 14.05 5.34 20.61 14.09 5.39 21.24 15.23 5.42 22.52 15.17 5.47 23.79 16.16 5.52
30 16.45 12.08 5.97 18.33 12.28 6.05 18.96 13.36 6.08 20.19 13.40 6.15 20.82 14.47 6.18 22.07 14.41 6.23 23.32 15.36 6.30
35 15.01 11.81 6.65 16.72 12.07 6.75 17.29 13.13 6.79 18.43 13.17 6.86 19.00 14.22 6.89 20.14 14.16 6.96 21.28 15.09 7.03
40 14.86 11.15 6.30 16.55 11.47 6.39 17.12 12.47 6.44 18.25 12.51 6.49 18.81 13.51 6.52 19.94 13.46 6.59 21.07 14.34 6.66
46 11.84 10.10 6.14 13.19 10.85 6.22 13.63 11.50 6.26 14.52 11.84 6.32 14.98 12.78 6.36 15.89 12.73 6.42 16.78 13.55 6.48

Ceiling type
Model: ABYG36LRTE × 2
AFR
m
3
/h
3,800
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 17.44 14.10 2.73 19.42 14.19 2.77 20.08 15.43 2.79 21.40 15.49 2.82 22.07 16.71 2.83 23.39 16.65 2.86 24.72 17.74 2.89
-10 17.26 13.96 2.74 19.23 14.05 2.78 19.88 15.28 2.79 21.20 15.32 2.82 21.85 16.55 2.83 23.16 16.48 2.86 24.48 17.56 2.89
0 17.10 13.83 2.91 19.05 13.92 2.95 19.69 15.13 2.97 20.99 15.18 3.00 21.64 16.38 3.02 22.95 16.32 3.05 24.24 17.38 3.08
5 17.06 13.80 3.04 19.01 13.88 3.09 19.65 15.09 3.11 20.94 15.13 3.14 21.60 16.35 3.16 22.89 16.28 3.18 24.19 17.35 3.21
10 16.88 13.77 3.42 18.81 13.86 3.47 19.44 15.06 3.49 20.72 15.12 3.52 21.37 16.32 3.54 22.65 16.27 3.58 23.94 17.32 3.62
15 16.40 13.61 3.53 18.25 13.84 3.59 18.89 15.04 3.61 20.12 15.09 3.64 20.74 16.30 3.66 21.99 16.23 3.70 23.23 17.28 3.74
20 16.62 13.74 3.93 18.50 13.97 4.00 19.14 15.19 4.01 20.40 15.23 4.05 21.03 16.46 4.08 22.29 16.40 4.12 23.56 17.46 4.15
25 16.78 13.75 4.67 18.69 13.98 4.74 19.33 15.20 4.76 20.61 15.25 4.81 21.24 16.48 4.83 22.52 16.41 4.88 23.79 17.48 4.93
30 16.45 13.07 5.33 18.33 13.29 5.40 18.96 14.45 5.43 20.19 14.49 5.49 20.82 15.65 5.51 22.07 15.59 5.56 23.32 16.62 5.63
35 15.01 12.77 5.94 16.72 13.06 6.02 17.29 14.20 6.06 18.43 14.24 6.12 19.00 15.39 6.15 20.14 15.32 6.21 21.28 16.32 6.27
40 14.86 12.06 5.62 16.55 12.41 5.70 17.12 13.49 5.74 18.25 13.53 5.79 18.81 14.62 5.82 19.94 14.57 5.88 21.07 15.51 5.94
46 11.84 10.93 5.48 13.19 11.74 5.55 13.63 12.44 5.59 14.52 12.81 5.64 14.98 13.83 5.68 15.89 13.77 5.73 16.78 14.65 5.78
- 153 -
6-1. Model: AOYG72LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
