Fujitsu Ceiling Type Design & Technical Manual

¢
Heating capacity (Triple)

Cassette type
Model: AUYG30LRLE × 3
AFR
m
3
/h
4,800
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.56 12.47 6.70 12.16 6.83 11.86 6.97 11.56 7.09
-15 -16 19.57 7.57 19.11 7.73 18.64 7.89 18.18 8.04 17.72 8.20
-10 -11 22.81 8.04 22.27 8.21 21.73 8.38 21.19 8.54 20.65 8.71
-5 -7 25.33 8.39 24.73 8.56 24.12 8.73 23.52 8.91 22.92 9.08
0 -2 27.31 8.47 26.66 8.65 26.00 8.83 25.35 9.00 24.71 9.16
5 3 30.86 8.49 30.12 8.67 29.39 8.85 28.65 9.01 27.92 9.15
7 6 31.19 8.50 30.44 8.68 29.70 8.86 28.96 9.03 28.22 9.15
10 8 32.64 8.45 31.86 8.61 31.08 8.80 30.29 8.97 29.53 9.15
15 10 33.88 8.44 33.07 8.61 32.26 8.79 31.45 8.97 30.65 9.10
20 15 30.48 7.37 29.75 7.51 29.02 7.67 28.30 7.83 27.57 7.93
24 18 31.16 7.33 30.42 7.47 29.67 7.63 28.93 7.79 28.20 7.89

Duct type
Model: ARYG30LMLE × 3
AFR
m
3
/h
6,300
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-20 -21 12.77 6.73 12.47 6.87 12.16 7.01 11.86 7.15 11.56 7.28
-15 -16 19.57 7.77 19.11 7.93 18.64 8.09 18.18 8.25 17.72 8.41
-10 -11 22.81 8.25 22.27 8.42 21.73 8.59 21.19 8.77 20.65 8.94
-5 -7 25.33 8.60 24.73 8.78 24.12 8.96 23.52 9.14 22.92 9.32
0 -2 27.31 8.69 26.66 8.87 26.00 9.05 25.35 9.24 24.71 9.40
5 3 30.86 8.71 30.12 8.90 29.39 9.08 28.65 9.24 27.92 9.38
7 6 31.19 8.72 30.44 8.90 29.70 9.08 28.96 9.27 28.22 9.39
10 8 32.64 8.66 31.86 8.84 31.08 9.03 30.29 9.20 29.53 9.39
15 10 33.88 8.66 33.07 8.83 32.26 9.02 31.45 9.21 30.65 9.33
20 15 30.48 7.56 29.75 7.70 29.02 7.87 28.30 8.03 27.57 8.13
24 18 31.16 7.52 30.42 7.66 29.67 7.83 28.93 7.99 28.20 8.09

Ceiling type
Model: ABYG30LRTE × 3
AFR
m
3
/h
4,980
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC TC
kW kW kW kW kW kW
-20 -21 12.77 6.56 12.47 6.70 12.16 6.83 11.86 6.97 11.56 7.09
-15 -16 19.57 7.57 19.11 7.73 18.64 7.89 18.18 8.04 17.72 8.20
-10 -11 22.81 8.04 22.27 8.21 21.73 8.38 21.19 8.54 20.65 8.71
-5 -7 25.33 8.39 24.73 8.56 24.12 8.73 23.52 8.91 22.92 9.08
0 -2 27.31 8.47 26.66 8.65 26.00 8.83 25.35 9.00 24.71 9.16
5 3 30.86 8.49 30.12 8.67 29.39 8.85 28.65 9.01 27.92 9.15
7 6 31.19 8.50 30.44 8.68 29.70 8.86 28.96 9.03 28.22 9.15
10 8 32.64 8.45 31.86 8.61 31.08 8.80 30.29 8.97 29.53 9.15
15 10 33.88 8.44 33.07 8.61 32.26 8.79 31.45 8.97 30.65 9.10
20 15 30.48 7.37 29.75 7.51 29.02 7.67 28.30 7.83 27.57 7.93
24 18 31.16 7.33 30.42 7.47 29.67 7.63 28.93 7.79 28.20 7.89
- 162 -
6-2. Model: AOYG90LRLA 6. Capacity table
OUTDOOR UNIT AOYG72-90LRLA OUTDOOR UNIT AOYG72-90LRLA
