Fujitsu Ceiling Type Design & Technical Manual

¢
Airflow
0
50
100
150
200
0 50 100 150 200 250 300 350 400
Static pressure of Fresh air intake kit (Pa)
1-way intake
2-way intake
Airflow (m³/h)
1,000
Measurement position of shown in the graph
For 2-way intake
1,000
For 1-way intake
Measurement position of shown in the graph
Unit: mm
- 304 -
10-3. Fresh air intake kit for cassette type (UTZ-VXRA) 10. Optional parts installation
