Fujitsu FUTRO S720 User Manual

Getting started
Connecting microphone, headphones, line-out
and line-in devices
MicrophoneHeadphonesLine-out dev ices
► Connect the microphone to the microphone port.
► Connect the headphon es to the
headphones po rt.
► Connect line-out devices to the audio output.
► Connect the external line
-in devices to the audio input.
Connecting the device to the network (LAN)
LAN
► Connect the 10/100/1000 Base T network cable to the RJ45 LAN port.
Connecting the mains adapter
Preparingforo perationPowercable
Observe the safety n
otes in the en closed "Safety/Re gulations" manual.
The s upplied power c
able conforms to the requireme nts of the country in
which you purchase
d your device. Make sure that the po wer cable is approved
for use in the count
ry in which you intend to use it.
2
1
3
► Connect the mains c able (1) to the mains adapter.
► Connect
the mains adapter cable (2) to t he DC jack (DC IN) of the device.
► Plug the mains cable (3) into a m ains socket.
24 Fujitsu

Fujitsu FUTRO S720 Specifications

General

Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Processor frequency	1.65 GHz
Internal memory	2 GB
Internal memory type	-
Storage media	Flash
Card reader integrated	No
Total storage capacity	16 GB
Storage drive interface	mSATA
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Product color	Black
Cable lock slot type	Kensington
Operating system installed	Windows Embedded 8 Standard
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	195 mm
Width	52 mm
Height	251 mm
Weight	1300 g
