Fujitsu FUTRO S720 User Manual

System expansio ns
Replacing the lithium battery
In order to permanently save the system information, a lithium battery is installed to provide
the CMOS-memory w ith a current. A corresponding error message notifies the user when the
charge is too low or the battery is empty. The lithium battery must then be replaced.
Incorrect r eplacement of the lithium battery may lead to a r isk of explosion!
The lithium battery may be replaced only with an identical battery or with
a type recommended by the manufacturer.
Do not dispose of lithium batteries with household waste. They must be disposed
of in accordance with local regulations concerning special waste.
Make sure that you observe the correct polarity when replacing the lithium
battery. The plus pole must be on the top!
Lithiumbattery,Replacing,Replacing,Replacing,lithiumbatteryBattery
The lithium battery holder exists in different designs that function in the same way.
1
2
3
1
2
3
► Press t
he catch in the direction of the arrow (1).

The battery jumps out of the holder slightly.
► Remov
e the battery (2).
► Push th e new lithium battery of the identical type into the holder (3) and
press it down until it engages.
Fujitsu 61

Fujitsu FUTRO S720 Specifications

General

Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Processor frequency	1.65 GHz
Internal memory	2 GB
Internal memory type	-
Storage media	Flash
Card reader integrated	No
Total storage capacity	16 GB
Storage drive interface	mSATA
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Product color	Black
Cable lock slot type	Kensington
Operating system installed	Windows Embedded 8 Standard
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	195 mm
Width	52 mm
Height	251 mm
Weight	1300 g
