Fujitsu FUTRO S720 User Manual

Contents
Contents
ValidityoftheReferenceManual ....................................................... 5
Notational conventions .................................................................. 5
Ports and operating elemen
ts .........................................................
6
Frontview .............................................................................. 6
Rearview .............................................................................. 7
Securityfunctions ....................................................................... 8
Property and data prote
ction .........................................................
8
SecurityLockdevice ................................................................ 9
Securing USB cove rs (o
ptional) . . . ...................................................
9
Importantnotes ........................................................................ 11
Safetynotes ............................................................................ 11
Important notes on preparing your FUTRO S720 /S920/S930 or ESPRIMO A525-L for use via
the Power over Ethernet module . . ....................................................... 12
Important notes on preparing your FUT RO S920/S930 for use with an external graphics
card ................................................................................... 12
Transporting the device .................................................................. 13
Cleaningthe device ..................................................................... 13
Energysaving, disposaland recycling .................................................... 14
FCCComplianceStatement ............................................................. 15
FCCClass B Compliance Statement .................................................. 15
Getting start
ed .........................................................................
16
Setting up the
device ....................................................................
16
Vertical oper
atingposition ............................................................
17
Horizontal o
peratingposition .........................................................
19
Connecting e
xternaldevices .............................................................
21
Ports on the d
evice ..................................................................
21
Connecting
amonitor ................................................................
22
Connecting
themouse ...............................................................
22
Connectin
g the keyboard . ...........................................................
22
Connectin
gexternaldevices totheserialinterface .....................................
23
Connecti
ngexternaldevices totheUSBports .........................................
23
Connecti
ng microphone, headphones, line-out and line-in devices . . .....................
24
Connecti
ngthedevice tothenetwork(LAN) ...............................................
24
Connect
ing the mains adapter ...........................................................
24
Operation .............................................................................. 25
Switchthedeviceon .................................................................... 25
Operating systems and management (device-dependen t) . . . . . ............................. 25
eLux . . ............................................................................. 25
Windows® Embedded & Window s® 10 IoT E nterprise . . . . . ............................. 26
ScoutEnterprise– Themanagementsolutionfor ThinClients ........................... 27
Switchingoffthedevice ................................................................. 28
Activatingpowersaving mode(FUJITSU ThinClient FUTROonly) ...................... 28
OpenBIOS Setup ....................................................................... 28
PXE system boot . ...................................................................... 28
BIOSUpdate ........................................................................... 29
Makingsystem settings .............................................................. 29
Executing a system update . . . ....................................................... 29
BIOSupdate usingaUSB stick ....................................................... 29
Fujitsu 3

Fujitsu FUTRO S720 Specifications

General

Processor cores	2
Processor model	GX-217GA
Processor family	AMD G
Processor frequency	1.65 GHz
Internal memory	2 GB
Internal memory type	-
Storage media	Flash
Card reader integrated	No
Total storage capacity	16 GB
Storage drive interface	mSATA
On-board graphics card model	AMD Radeon HD 8280E
Ethernet LAN	Yes
Cabling technology	10/100/1000Base-T(X)
USB 2.0 ports quantity	5
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
Product color	Black
Cable lock slot type	Kensington
Operating system installed	Windows Embedded 8 Standard
Sustainability certificates	EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth	195 mm
Width	52 mm
Height	251 mm
Weight	1300 g
