Working with the Tablet PC
Using the stylus pen
Pen
2
3
5
4
1
1 = pen tip
2 = pen button (= right mouse button)
3 = pen button (= delete fun ction)
4 = charging contacts
5 = eyelet for optional pen strap
You can use the pen on your Tablet PC as an electronic writing implement to select items, and to
navigate through pro grams on it. Programs that support handwriting recognition also allow y ou to
write characters directly on the screen with th e pen. You can also use the pen as a drawing tool.
A pen tet her is available as an optional extra and you can use this to tie the
eyelet on t he pen to the eyelet on the Tab let PC.
Use only the pen provided with your Tablet PC. Do not use substitutes that
were not designed for your Tablet PC. Replace the stylus tip if it is worn.
The warranty d oes not cover a scratched screen.
While writing, you should take care not to scratch the surface of the
display (e.g. with a wristwatch or bracelet).
The Tablet PC’s pen is an electronic instrument that can be damaged if
used improperly. Handle the pen with care.
The following list contains guidelines for proper pen handling :
• Do not gesture with the pe n.
• Do not use the pen as a pointer.
• Do not use the pen on surfaces other than the screen of the Tablet PC.
• Do not try to turn the thumb grip o n the pen. The g rip is used to place
the pen in its slot or to remove it from the slot.
• Never store the pen with the tip bearing the weight of the pen (e.g. with the tip
down in a pen holder). If the pen is stored with the tip pointing down, this may
have an adverse effect on the pe n mechanism (particularly at high temperatures).
In this case the pen tip may react as though it is constantly being pressed down.
To avoid damage, the pen should be stored in the slot when not in use.
Thepencanbeinfluenced by electrom agnetic fields (cursor quivers or
jumps). There may be a few areas on the screen w here the cursor quivers
slightly in spite of pressing t he pen down firmly.
Fujitsu 29
