Accessories for your Tablet PC (opti
onal)
Keyboard dock (optional)
The keyboard dock is a device which has been optimised for convenient input of te xts and
allows connection to an Ethernet/LAN. You only need to dock the Tablet PC.
Components of the keyboard
dock
Keyboarddo ckPorts
1
3
4
5
6
2
8
7
1 = Release button
2 = Docking port for the Tablet PC
3 = F Lock display (run Fn functions by
pressing the keys directly)
4 = Num Lock indicator (switch virtual
keypad on and off)
5 = Caps Lock indicator ( switch upper case
writing function on and off)
6 = Scroll Lock display (roles, function
application depend ant)
7 = DC input connector (DC IN)
8 = LAN port
Amicrofibre cloth is provided with your keyboard dock. To protect your Tablet
PC’s touchscreen, we recom m end placing the microfibre cloth between the
keyboard and the touchscreen when the device is fo lded closed.
Fujitsu 51
