3-3
Figure 3.3 Display Unit, Top view, cover removed
Figure 3.4 Display Unit, rear view, cover removed
Fuse
Maintenance
Switch, (S2)
Lower shield cover removed (AC set) Lower shield cover removed
(
DC set
)
SPU Board
(03P9230)
Heat Sinker
GC-8 Board
(64P1106)
Optional
Lower Shield
Cover
PM board(03P9225)
Optional
