3-18
Scanner Unit, stern side, cover removed
Scanner Unit, stern side, cover and RF module removed
Scanner Unit, fore side, cover removed
TX-HV connector
RF module
Antenna drive gear
Scanner motor
Connectors for
RF module
Antenna cable
EMI cores
Reed switch
(
S901
)
BP GEN Board
MP-3795
03P9242
Cable to RF module
