Furuno FR-1505 MARK-3 Series User Manual

3-27
FR-1505 MARK-3 Ñ RTR-067 Ò
Figure 3.16 RF module, top view
Figure 3.17 RF module, bottom view
IF AMP Board (03P9232) and RFC Board (03P9243) are the same as those of FR-1510 MARK-3.
See pages 19 and 20.
Circulator
(RC-3686)
MIC
(RU-9253/9371)
IF Amp Board
(03P9232)
RFC Board
(03P9243A)
VR1 on MODULATOR
Board (03P9244D) for
magnetron current
ad
j
ustment
Magnetron
(MG5389/
E3560)
MODULATOR
Board
(03P9244D)
Pluse
Transformer
(
RT-9025
)
