Furuno FR-1505 MARK-3 Series User Manual

3-17
3.2 Adjustment (Scanner Unit)
Scanner Unit, side view (XN-20AF)
Antenna radiator, bottom view (XN-20AF)
Scanner Unit, top view, antenna radiator removed
10 kW and 20 kW scanner units
are the same in size.
No feeder waveguide visible
Feeder waveguide
Radiator bracket
Guide pin hole
Rotary joint
O-ring
Guide pin hole
