3-19
FR-1525 MARK-3
Ñ
RTR-063
Ò
Figure 3.12 RF module, top view
Figure 3.13 RF module, bottom view
RFC Board
(03P9243B)
VR1 on MODULATOR
Board (03P9244B) for
magnetron current
ad
j
ustment
Circulator
(RC-3686)
MIC
(RU-9253/9371)
IF Amp Board
(03P9232)
Magnetron
(MG5436)
MODULATOR
Board
(03P9244B)
Pulse
Transformer
(RT-9023)
