4. VIDEO SOUNDER OPERATION
4-14
Activating/deactivating the speed-dependent picture advance mode
1. Press the MENU key followed by the SOUNDER MENU soft key.
2. Select PRR LEVEL.
3. Press the EDIT soft key to open the setting window.
4. Use the Trackball
to select SPD SENSING PRR.
5. Press the RETURN soft key followed by the MENU key to close the menu.
Note: Use the same speed data sentence (STG or STW) throughout the network for
smooth advancement of the sounder picture. See the paragraph 6.5 for how to output data
through the network.
4.10 Display Colors
You can select the number of colors and background color to display as follows:
1. Press the MENU key.
2. Press the SOUNDER MENU soft key.
3. Select HUE, then press the EDIT soft key to show the hue window.
HUE
â–²
1
â–¼
Hue window
4. Use the Trackball
to select hue number, referring to the table below. (You can see the
result of your selection on the display.)
Hue no. and background and echo colors
Hue No. Echo Color Background Color
1 16 color Blue
2 8 color Blue
3 16 color Dark blue
4 8 color Dark blue
5 16 color White
6 8 color White
7 16 color Black
8 8 color Black
9 Monochrome yellow, eight intensities
5. Press the RETURN soft key followed by the MENU key to close the menu.
