1.5.4 Selecting image source
When more than one network radar or network sounder is connected to the equipment, you
may select an image source for each as shown below. This is not necessary when only one
network radar or network sounder is connected.
1. Press the DISP key.
2. Press any soft key to show the following display.
▲
SELECT
SOURCE
EDIT
RETURN
IF THERE IS MORE THAN
ONE NETWORK RADAR OR
ECHO SOUNDER, YOU MAY
SELECT THE IMAGE
SOURCES FOR DISPLAY.
RADAR SOURCE
1
(HOST NAME: NAVNET1)
SOUNDER SOURCE
ETR1 (HOST NAME: SOUNDER)
AUX SOURCE AUX 1 (HOST NAME: WXFAX)
IP ADDRESS 172.031.003.003
DEVICE NUMBER 1 (HOST NAME: NAVNET-1)
Select source menu
3. Use the Trackball to select RADAR SOURCE, SOUNDER SOURCE or AUX SOURCE
as appropriate, then press the EDIT key.
Radar source
RADAR SOURCE
▲
1 (NAVNET1)
2 (NAVNET2)
3 (NAVNET3)
4 (NAVNET4)
▼
SOUNDER SOURCE
▲
ETR0 (SOUNDER)
ETR1 (SOUNDER1)
ETR2 (SOUNDER2)
ETR3 (SOUNDER3)
ETR4 (SOUNDER4)
ETR5 (SOUNDER5)
ETR6 (SOUNDER6)
ETR7 (SOUNDER7)
ETR8 (SOUNDER8)
ETR9 (SOUNDER9)
▼
Sounder source
Aux source
AUX SOURCE
▲
AUX1 (WXFAX)
AUX2 (WXFAX1)
AUX3 (WXFAX2)
AUX4 (WXFAX3)
▼
Radar source and sounder source windows
4. Use the Trackball to choose source.
5. Push the ENTER knob to set.
6. Press the DISP key to finish.
7. Turn the power off and on again.
