3. PLOTTER OPERATION
3-14
3.5.4 C-MAP charts
Cursor and data display
Besides its fundamental functions of providing position data, the cursor can also show
information about caution area, depth area, source of data, etc. on C-MAP charts. In
addition, you can display information about an icon by placing the cursor on it.
1. Move the Trackball to turn the cursor on.
2. Use the Trackball to place the cursor on the position desired.
3. Push the ENTER knob to open the Objects window.
Objects
Spot Sounding
Depth area
Exclusive economic zone
Military practice area
Restricted area
Source of data
Objects window
4. Use the Trackball to select the item desired.
5. Push the ENTER knob to display details for object selected.
Depth area
Depth range value1
0.00 Meters
Depth range value2
1829.00 Meters
Example of caution area window
6. Press the CANCEL soft key to close the window.
7. Press the CANCEL soft key to finish.
