6. DATA TRANSFER
6-7
Mark data format
$PFEC, GPmrk, xxxxxxxx, xxxxxxxx, xxxxxxxx, x, x, x, xxxxxxxx, c----c<CR><LF>
1
2
3
4
5
6
8
7
Mark data format
1: Geodetic latitude (Latitude in minutes, hexadecimal)
2: Longitude (longitude in minutes, hexadecimal)
3: Mercator latitude (latitude in minutes, hexadecimal)
4: Mark code
5: Color (0: black, 1: red, 2: yellow, 3: green, 4: light-blue, 5: purple, 6: blue, 7: white)
6: Status (hexadecimal number)
(b0: (0/1)=mark/line), b1: (0/1)=(memory/replay)
b2: reserve
b3: External event (0/1)=(no/YES), b4: Line connection (=1: connect to the previous)
b [5, 6]: Line type
7: Time entered (Hexadecimal number, total seconds from 1986/1/1 00:00:00 as reference)
8: Comment (Max. 15 characters, including the code not required for NMEA)
6.3 Loading Waypoint Data from Yeoman
Waypoint data can be loaded from a Yeoman to this equipment. Connect the Yeoman to a
DATA port on this equipment and then follow the procedure below.
1. Press the MENU key.
2. Press the SYSTEM CONFIGURATION key.
3. Press the DATA TRANSFER soft key.
4. Press the RECEIVE YEOMAN DATA soft key.
5. You are asked if you are sure to receive waypoint data from Yeoman equipment. Push
the ENTER knob to receive the data. The message “NOW RECEIVING YEOMAN DATA.
PUSH SOFT KEY ‘STOP’ TO STOP RECEIVING.” Is displayed. If waypoint capacity is
reached the message “WAYPOINTS FULL. NO MORE WAYPOINT CAN BE
RECEIVED. PUSH ANY KEY TO STOP.” appears. To stop receiving, press the STOP
soft key.
After waypoints have been received, press the MENU key.
