7.10 Nav Graphic Display Setup
The nav graphic display (see paragraph 3.1.2) shows either the compass display or the
wind angle display, together with depth and temperature graphs. You may choose which to
display and setup the depth and temperature graphs as follows:
1. Press the MENU key to open the menu.
2. Press the SYSTEM CONFIGURATION, SYSTEM SETUP, HOT PAGE & NAV DISP
SETUP and NAV GRAPHIC DISPLAY SETUP soft keys.
NAV
GRAPHIC
EDIT
RETURN
GRAPHIC METER COMPASS
DEPTH GRAPH UP~DATE 1S/DOT
TEMP GRAPH UP-DATE 1S/DOT
NAV GRAPHIC menu
3. Choose GRAPHIC METER and press the EDIT key.
GRAPHIC METER
▲
{
▼
~
COMPASS
WIND ANGLE
Graphic meter window
4. Choose COMPASS or WIND ANGLE as appropriate and press the ENTER soft key.
5. Choose DEPTH GRAPH UP-DATE and press the EDIT soft key.
DEPTH GRAPH UP-DATE
▲
{
{
{
▼
~
0.5s./dot
1s/dot
2s/dot
4s/dot
Depth graph up-date window
6. Choose desired update period/number of dots and press the ENTER soft key.
7. Set TEMP GRAPH UP-DATE similarly.
8. Press the MENU key to close the menu.
