Furuno NAVNET 1824C User Manual

3. PLOTTER OPERATION
3-7
3.1.4 Nav data display
The nav data display provides comprehensive navigation data, and it is shown in a
three-screen combination display. The user may select what data to display and where to
display it. For details see the paragraph “7.8 Nav Data Display Setup.”
Appropriate sensors are required. Bars ( - -) appear when corresponding sensor is not
connected.
POSITION
34° 34. 5678' N
120° 34. 5678'
W
SOGWPT POSITION
COURSESTW
10.0 kt
RANGEBEARING
9.2° M
TEMPDEPTH
Speed over ground
Position
Water temperature
Range to
waypoint
Course
Speed through
water
Bearing to
Waypoint
Waypoint
Position
Depth
34° 14. 5678' N
120° 14. 5678'
W
10.0 kt
101.6° M
0.18 nm
1324.1 ft
18.2 °C
Nav data displays
