1.4.2 Hue
You may select the colors for the radar and plotter displays as below.
1. Press the POWER/BRILL key momentarily.
2. Press the HUE soft key to show the hue setting window.
HUE
▲
DAY
NIGHT
TWILIGHT
MANUAL SET
▼
Hue window
3. Operate the Trackball to select hue desired, referring to the table below. MANUAL SET
follows the color settings on the CHART DETAILS menu for the plotter and the RADAR
DISPLAY SETUP menu for the radar.
Night Day Twilight
Characters Red Black Green
Radar ring Red Green Green
Radar echo Orange Multi Yellow
Background Black White Blue
Landmass (plotter) Orange* Light-orange* Orange*
* = Beige and light-beige on C-MAP display unit.
4. Hit the RETURN soft key to finish.
Note: When using the overlay screen, the own ship track will be hidden if the radar
background and own ship track are blue and the “MANUAL SET” hue setting is used. In this
case, set HUE to other position and then return to “MANUAL” to show the own ship track in
black.
