A-4 MAC™ 3500 Resting ECG Analysis System Revision L
2021337-036
Technical Specifications: Communications with MUSE System
Communications with MUSE System
Item Description
Optional:
Infrared
Serial cable
Internal modem/fax Fax compatibility Class 2 Group 3
External modem fax Fax compatibility Class 2 Group 3
Fax
Wireless (MobileLink)
1
MobileLink uses WEP security protocols and (in some countries) Cisco LEAP
authentication/security.
LAN
1
Communication with MUSE system over LAN through internal RJ-45 jack.
(Requires additional MUSE software and installation.)
1. Requires additional MUSE software and installation.
Display
Item Description
Display type: 6.5 in (165 mm) diagonal graphics backlit AM LCD (color optio
nal)
Display resolution: 640 x 480 pixels with waveform enhancement
Display data: Heart rate, patient name, ID, clock, waveforms, lead labels, speed, gain and filter settings,
warning messages, prompts, and h
elp messages. 6 leads maximum.
Writer
Item Description
Writer technology: Thermal dot array
Writer speeds: 5, 12.5, 25, & 50 mm/s (same as displayed)
Number of traces: 3, 6, or 12 user selectable (same as displayed)
Writer sensitivity/gain: 2.5, 5, 10, 20, 10/5 (split calibration) mm/mV (same as displayed)
Writer speed accuracy:
+2%
Writer amplitude accuracy:
+5%
Writer resolution: Horizontal 1000 dpi @ 25 mm/s, 200 dpi vertical
