4-40
MAC™ 3500 Resting
ECG Analysis System
Revision L
2021337-036
T
rou
bleshooting:
CPU PCB Input/Output Signals
Floppy Disk Drive, J13
(for floppy drive — not installed
Pin No.
Signal
1
5V Power
2
Index
3
5V Power
4
Drive Select 0
5
5V Power
6
Disk Change
7
NC
8
Media Sense 0
9
Media Sense 1
10
Motor Select 0
11
NC
12
Direction
13
NC
14
Step
15
Ground
16
Write Data
17
Ground
18
Write Gate
19
Ground
20
Track 0
21
Ground
22
Write Protect
23
Ground
24
Read Data
25
Ground
26
Head Select
79
81
