GE MAC 3500 Service Manual

Revision L MAC™ 3500 Resting ECG Analysis System B-3
2021337-036
Software/Hardware Compatibility: Introduction
Introduction
Before ordering software upgrades or replacement CPUs, communication boards, or
display assemblies, you need to know which components are compatible.
Display Compatibility
The following display assemblies are interchangeable and compatible with 801212–
006, 801212–007, and 801212–008 circuit boards. However, the components used
to construct the display assemblies are not interchangeable.
Table 1. Compatible Display Assemblies
Part Number Description
Display Type (10.5”)
Make Model Type
2017484–001 Display Assembly MAC 5500/MAC 5000 NEC -64E CCFL/CMOS
2017484–002 Display Assembly MAC 5500/MAC 5000 NEC -59D CCFL/CMOS
2017484–003 Display Assembly MAC 5500/MAC 5000 AUO -V0 CCFL/CMOS
2017484–004 Display Assembly MAC 5500/MAC 5000 AUO -V1 LED/LVDS
Table 2. Compatible Display FRU Kits
Part Number Description
Display Type (10.5”)
Make Model Type
2019106–002 FRU Display MAC5000 PROD CODE MH NEC -59D CCFL/CMOS
2019106–003 FRU Display MAC5000 PROD CODE MP/WT NEC -64E CCFL/CMOS
2019106–004 FRU Kit Display AUO AUO -V0 CCFL/CMOS
2019106–005 FRU Kit Display AUO AUO -V0 CCFL/CMOS
2019106–007 FRU Kit Display AUO AUO -V1 LED/LVDS
