9 SCADA Communications
P50 Agile P253
9-12
P253/EN M/C
2.2.12 Protocol Mapping
Sr. No.
INF
Description
GI
TYP
COT
FUN
1
Semantics of INFORMATION NUMBER: System Functions in monitor direction
0 End of general interrogation - 8 10 255
0 Time synchronization - 6 8 255
2 Reset FCB - 5 3 160
3 Reset CU - 5 4 160
4
Start/Restart
-
5
5
160
5
Power on
-
5
6
160
Note: X under GI heading means DI Status is included in General Interrogation response.
Sr. No. INF Description GI TYP COT FUN
2 Semantics of INFORMATION NUMBER: Status Indications in monitor direction
19 Trip LED X 1 1,7,9,20,21 160
22
Local parameter setting
X
1
11,12
160
27
Opto I/P-1
X
1
1,7,9
160
28 Opto I/P-2 X 1 1,7,9 160
29 Opto I/P-3 X 1 1,7,9 160
30 Opto I/P-4 X 1 1,7,9 160
31 Opto I/P-5 X 1 1,7,9 127
32
Opto I/P-6
X
1
1,7,9
127
36
TCS Alarm
X
1
1,7,9
160
134 Password Reset - 2 1,7 124
135 CBOpr Alm X 2 1,7,9 124
