5 Configuration
P50 Agile P253
5-34
P253/EN M/C
2.3.14 Disturbance Record Menu
2.3.14.1 View / Edit Settings
DISTURBANCE REC
Password protected window for “Disturbance Record” setting:
Trigger Position
Trigger Position
50%
Editable setting
By using the (+ /5) or (- /6) key, the desired Trigger Position can be
set. The setting range is from 10% to 90% in steps of 1.
2.3.15 Commissioning Test Menu
2.3.15.1 View / Edit Settings
COMMISSION. TEST
Password protected window for “Commissioning Test” settings:
Test Mode, Test Pattern, Contact Test and Test LEDs.
Test Mode
Disabled
Editable setting
By using the (+ /5) or (- /6) key, the desired Test Mode be set as
Disabled/Test Mode/Contacts Blocked.
Test Pattern
000000
Editable setting
By using the (+ /5) or (- /6) key, the desired Test Pattern can be set
as ‘1’=Operated / ‘0’=Not Operated.
Contact Test
No Operation
Editable setting
By using the (+ /5) or (- /6) key, the desired Contact Test can be set
as No Operation / Apply Test / Remove Test
Test LEDs
No Operation
Editable setting
By using the (+ /5) or (- /6) key, the desired Test LEDs can be set as
No Operation / Apply Test.
2.3.16 Group 1 Menu
2.3.16.1 Edit Settings
GROUP 1
Password protected window for
“GROUP 1’’
setting:
SYSTEM CONFIG, OVERCURRENT, NEG SEQUENCE O/C, EARTH
FAULT 1, EARTH FAULT 2, THERMAL OVERLOAD, LOSS OF LOAD,
CB FAIL, STALL DETECTION and LIMITS NB STARTS.
Note: Group 1 setting will be seen only when it is enabled in
Configuration setting.
