– 30 –
Glass Touch Panel
The glass touch panel is attached to the control
panel with two 1/4-in. hex-head screws at the
bottom and 2 tabs located at the top.
To remove the glass touch panel:
1. Remove the main logic board. (See Main Logic
Board.)
2. Remove the two 1/4-in. hex-head screws that
attach the glass touch panel to the control
panel.
3. Disengage glass touch panel tabs from slots in
control panel.
Glass Touch Panel Removed
Tab
Tab
Tab
4. Slide the control panel frame off the front of the
range.
Cooktop Assembly
To remove the cooktop assembly on PHS925:
1. Disconnect power to the range.
2. Remove the control panel. (See
Control Panel.)
3. Remove the six 1/4-in. hex-head screws that
attach the control panel frame
(Continued next page)
