– 62 –

High Limit Thermostat

Model PHS925

In the event of an over-heat condition under the

cooktop, the high limit thermostat will open at 350°F.

and disconnect L2 voltage from the bake, broil,

and convection elements. The thermostat is non-

resetable.

To replace the high limit thermostat:

1. Raise the front of the cooktop (See Cooktop

Assembly, follow steps 1 through 6.), and then

support the cooktop.

2. Cut off the plastic wire tie.

3. Disconnect the 2 wires.

4. Remove the two 1/4-in. hex-head screws that

attach the thermostat to the range.

Note: When installing the high limit thermostat, be

sure to secure the wires to the thermostat with a

new plastic tie.

Plastic Tie

Disconnect

Cooling Fan Cover

Cooling Fan and FAD (Fan Apparency Device)

Model PHS925

The oven is equipped with a cooling fan located

under the cooktop and above the right side panel.

• The cooling fan comes on instantaneously when

any oven function is started.

• The cooling fan motor operates on 115 VAC and

has an approximate resistance value of 58 

To replace the cooling fan:

1. Raise the front of the cooktop (See Cooktop

Assembly, follow steps 1 through 6

.), and then

support the cooktop.

2. Remove the nine 1/4-in. hex-head screws and

the cooling fan cover.

(Continued next page)
