– 65 –

Bake Thermal Switch

Model PS978

In the event of an over-heat condition under the

cooktop, the bake thermal switch will open

at 230°F.

The switch is resetable.

The bake thermal switch is located to the left of the

clean thermal switch and attached to the thermal

switch bracket with two 1/4-in. hex-head screws. It

is necessary to remove the control panel to access

the switch bracket. (See

Control Panel.)

Clean Thermal Switch

Model PS978

In the event of an over-heat condition under the

cooktop, the clean thermal switch will open

at 250°F.

The switch is resetable.

The clean thermal switch is located to the right

of the bake thermal switch and attached to the

thermal switch bracket with two 1/4-in. hex-head

screws. It is necessary to remove the control panel

to access the switch bracket. (See Control Panel.)

Bake Thermal Switch

Clean Thermal Switch
