– 48 –

Bake Element

• The element is rated at 2850 watts, has an

approximate resistance value of 20 , and

draws approximately 12 amps.

• The bake element is located under the oven liner

ﬂ oor. The bake element terminals are located

behind the left side panel.

To remove the bake element on PHS925:

1. Disconnect power to the range.

2. Remove the range from the installation, and

then remove the left side panel. (See Left Side

Panel.)

3. Remove the center T-15 Torx screw from the

vertical trim.

4. Slide the aluminum foil insulation out from the

vertical trim.

5. Carefully peel the reﬂ ective tape from the

induction module air inlet vent.

6. Remove the T-15 Torx screw from the front side

of the top brace.

Aluminum Foil

Insulation

Reﬂ ective Tape

Vertical Trim

Top Brace

9. Remove the 1/4-in. hex-head screw from the

back of the top brace.

Note: Rear of top brace has a tab that is inserted in

a slot in back of range.

Tab

7. Remove the 1/4-in. hex-head screw and the

upper heat shield.

8. Remove the 1/4-in. hex-head screw that

attaches the lower heat shield to the range

frame.

Upper Heat Shield

Lower Heat Shield

(Continued next page)
