80224_MHW_650 L - 1250 L_07-2018_ENG - 21
2.4.5.
Digital inputs
Digital inputs
Digital inputs
dry contact
41
42
43
44
45
46
COM
IN1
IN2
IN3
IN4
IN5
Digital inputs
Digital inputs
NPN 24 V
, 4,5 mA
41
42
43
44
45
46
COM
IN1
IN2
IN3
IN4
IN5
Digital inputs
41
42
43
44
45
46
COM
IN1
IN2
IN3
IN4
IN5
GND
PNP digital inputs
+12/24 V max 3,6 mA
2.4.6.
Serial line
Serial line
7
8
9
46
47
48
B (Data -)
A (Data +)
Serial line
RS485 2-wires
2.4.7.
Analog output
Analog output
Analog output
0...10 V
, max 20 mA
0...20 mA, 4...20 mA,
Rout < 500Ω
7
8
30
29
2
8
25
-
+
Out A1
2. INST
ALLA
TION
22
24
