4.8.1. OUT.N - Selecting the output
Acronym Scrolling message Submenu Attributes
OUT.N OUTPUT NUMBER OUTPU R W
The parameter shows and sets the identifying number of the output to be configured.
Unit of measurement: Number
Options: 1...3
4.8.2. S.ou.x - Defining the output state
Acronym Scrolling message Submenu Attributes
S.ou.x DIGITAL OUTPUT STATUS OUTPU R W
The parameter shows and sets the state of the output with identifying number “x”.
The active direct output corresponds to the relay, output ON.
The active inverse output corresponds to the relay, output OFF.
The parameter only appears for OUT.N=2 and OUT.N=3.
Only INVRS for OUT.1
Unit of measurement: -
Options: DIREC = Direct output
INVRS = Inverse output
4.8.3. F.ou.x - Selecting the function assigned to relay, logic or Triac output
Acronym Scrolling message Submenu Attributes
F.ou.x OUTPUT FUNCTION OUTPU R W
The parameter shows and sets the function assigned to the output with identifying number “x”.
The parameter only appears for OUT.N=2 and OUT.N=3.
Only ALRM1 for OUT.1
Unit of measurement: -
Options: NONE = No assigned function
ALRM1
= Output for Alarm 1
ALRM2
= Output for Alarm 2
ALRM3
= Output for Alarm 3
ALRM4
= Output for Alarm 4
OR.12
= Alarm 1 OR Alarm 2
OR.123
= Alarm 1 OR Alarm 2 OR Alarm 3
O.1234
= Alarm 1 OR Alarm 2 OR Alarm 3 OR Alarm 4
AND.12
=
Alarm 1 AND Alarm 2
AND.123
=
Alarm 1 AND Alarm 2 AND Alarm 3
AND.1234
=
Alarm 1 AND Alarm 2 AND Alarm 3 AND Alarm 4
if model with digital inputs:
IN.DIG
=
Repetition of a digital input
4.8.4. IN.DG.N - Setting the digital input number
Acronym Scrolling message Submenu Attributes
IN.DG.N DIGITAL INPUT NUMBER OUTPU R W
The parameter shows and sets the number of the digital input assigned to the output.
The parameter appears if the parameter F.ou.x = IN.DIG.
Unit of measurement: Number
Options: 1...5 Model 1250 L with option 5 digital inputs
