80224_MHW_650 L - 1250 L_07-2018_ENG - 35
4.4.6. xxxxx - Model of indicator
Acronym Scrolling message Submenu Attributes
xxxxx MODEL INFO R
The parameter shows the model of the indicator.
xxxxx indicates the indicator model (650L.LV, 650L.HV, 1250L.LV and 1250L.HV only).
Unit of measurement: -
Options: 650.LV = 650 L indicator powered at 20...27 VAC/VDC
650.HV = 650 L indicator powered at 100...240 VAC/VDC
125.LV = 1250 L indicator powered at 20...27 VAC/VDC
125.HV = 1250 L indicator powered at 100...240 VAC/VDC
4.4.7. INDIC - Type of indicator
Acronym Scrolling message Submenu Attributes
INDIC MODEL OPTION INFO R
The parameter shows the type (xxxxx) of function.
Unit of measurement: -
Options: INDIC = The devices only operates as an indicator
4.4.8. OUT.A1 - Analog output 1 available
Acronym Scrolling message Submenu Attributes
OUT.A1 ANALOG OUTPUT AVAILABLE INFO R
If present, the parameter indicates that the analog output in voltge or current is installed on the indicator.
Unit of measurement: -
Options: -
4.4.9. x.IN.DG - Digital input available
Acronym Scrolling message Submenu Attributes
x.IN.DG DIGITAL INPUT AVAILABLE INFO R
If present, the parameter indicates how many digital inputs are installed on the indicator.
Unit of measurement: -
Options: 1.IN.DG = 1 digital input installed on the indicator (for 650 L only)
5.IN.DG = 4 digital input installed on the indicator (for 1250 L only)
4.4.10. RS485 - RS485 serial port available
Acronym Scrolling message Submenu Attributes
RS485 FIELDBUS AVAILABLE INFO R
If present, the parameter indicates that an RS485 is installed on the indicator.
Unit of measurement: -
Options: -
4. CONFIGURATION
