gefran 650 L User Manual

80224_MHW_650 L - 1250 L_07-2018_ENG - 69
4. CONFIGURATION
4.14.5. RTD.LO - Calibrating minimum resistance value
Acronym Scrolling message Submenu Attributes
RTD.LO US.CAL R W
The parameter appears if you are calibrating a custom I.MAIN RTD input.
To calibrate:
• apply a resistance corresponding to minimum scale value to the main input (for example, 18.52 Ω for Pt100 ;
• press the
key to acquire the calibration value.
Unit of measurement: -
Options: -
4.14.6. RTD.HI - Calibrating maximum resistance value
Acronym Scrolling message Submenu Attributes
RTD.HI US.CAL R W
The parameter appears if you are calibrating a custom I.MAIN RTD input.
To calibrate:
• apply a resistance corresponding to maximum scale value to the main input (for example, 390.48 Ω for Pt100);
• press the
key to acquire the calibration value.
Unit of measurement: -
Options: -
4.14.7. C.LO - Setting analog output minimum
Acronym Scrolling message Submenu Attributes
C.LO US.CAL R W
The parameter shows and sets the minimum analog output value.
You can change the displayed value with the
and keys.
To check the real voltage/current value on the output during calibration, measure it with a voltmeter/ammeter.
Unit of measurement: Converter points
Options: 0...65535
4.14.8. C.HIG - Setting analog output maximum
Acronym Scrolling message Submenu Attributes
C.HIG US.CAL R W
The parameter shows and sets the maximum analog output value.
You can change the displayed value with the
and keys.
To check the real voltage/current value on the output during calibration, measure it with a voltmeter/ammeter.
Unit of measurement: Converter points
Options: 0...65535
