gefran 650 L User Manual

80224_MHW_650 L - 1250 L_07-2018_ENG - 41
Unit of measurement: -
Options: J.TC = J thermocouple
K.TC = K thermocouple
R TC = R thermocouple
S TC = S thermocouple
T.TC = T thermocouple
C.TC = C thermocouple
D.TC = D thermocouple
B.TC = B thermocouple
E.TC = E thermocouple
L.TC = L thermocouple
L.GO.TC = L GOST thermocouple
U.TC = U thermocouple
G.TC = G thermocouple
N.TC = Termocoppia N PT2.TC = Pt20Rh / Pt40Rh thermocouple
INFR1 = IR sensor type 1
INFR2 = IR sensor type 2
INFR3 = IR sensor type 3
INFR4 = IR sensor type 4
PT100 = Pt100 resistance thermometer
PT.LIM = Pt 100 limitated resistance thermometer
JTP10 = JPT100 resistance thermometer
60MV = 0...60 mV sensor
20MA = 0...20 mA sensor
4-20M = 4...20 mA sensor
10V = 0...10 V sensor
2-10V = 2...10 V sensor
5V = 0...5 V sensor
1-5V = 1...5 V sensor
1V = 0...1 V sensor
0.2-1V = 0,2...1 V sensor
C.RTD = RTD sensor with user calibration
C.60MV = 0...60 mV sensor with user calibration
C.20MA = 0...20 mA sensor with user calibration
C.4-20 = 4...20 mA sensor with user calibration
C.10V = 0...10 V sensor with user calibration
C.2-10 = 2...10 V sensor with user calibration
C.5V = 0...5 V sensor with user calibration
C.1-5V = 1...5 V sensor with user calibration
C.1V = 0...1 V sensor with user calibration
C.0.2-1 = 0,2...1 V sensor with user calibration
4.5.2. SBR.E - Enabling Sensor Break Alarm (SBR)
Acronym Scrolling message Submenu Attributes
SBR.E SBR ENABLE INPUT R W
Enables open thermocouple probe error detection (sensor break alarm), also permitting infrared sensor management with
maximum 4Kohm output impedance.
The parameter only appears when a thermocouple type input is selected.
The parameter will be forced ON (see options) at each Power On
Unit of measurement: -
Options: On = Enable SBR alarm
Off = Disable SBR alarm
4. CONFIGURATION
