80224_MHW_650 L - 1250 L_07-2018_ENG - 63
4. CONFIGURATION
4.12.4. MSG.ER - Err message display
Acronym Scrolling message Submenu Attributes
MSG.ER NUM SCROLLING MSG WHEN MAIN INPUT IS ERR ERR HMI R W
The parameter shows and sets the number of the message assigned to Err (Pt100 in short circuit or input values below
minimum limit), i.e., the scrolling message shown on the display.
For more information on scrolling messages, see paragraph “3.1.2.2. Scrolling messages” on page 24.
If the parameter is set to “0” no message will be displayed for Err.
As default, MSG.ER is assigned the message “3” (for LANG1 corresponds to “INPUT SENSOR FAIL CONNECTION”, for
LANG2 corresponds to “ERRATA CONNESSIONE SONDA”).
Unit of measurement: Message number
Options: 0...25
4.12.5. MSG.SB - Sbr message display
Acronym Scrolling message Submenu Attributes
MSG.SB NUM SCROLLING MSG WHEN MAIN INPUT IS SB ERR HMI R W
The parameter shows and sets the number of the message assigned to Err (sensor break in short circuit or input values
above maximum limit), i.e., the scrolling message shown on the display.
For more information on scrolling messages, see paragraph “3.1.2.2. Scrolling messages” on page 24.
If the parameter is set to “0” no message will be displayed for Sbr.
As default, MSG.SB is assigned the message “4” (for LANG1 corresponds to ““SENSOR BROKEN”, for LANG2 corre-
sponds to “SONDA APERTA”).
Unit of measurement: Message number
Options: 0...25
4.12.6. LAnG - Display language
Acronym Scrolling message Submenu Attributes
LAnG MESSAGE LANGUAGE HMI R W
The parameter shows and sets the language for the scrolling messages.
Unit of measurement: -
Options: LANG1 = Language 1 (English)
LANG2 = Language 2 (Italian)
LANG3 = Language 3
4.12.7. SPEED - Message scrolling speed
Acronym Scrolling message Submenu Attributes
SPEED SCROLLING MESSAGE SPEED HMI R W
The parameter shows and sets the message scrolling speed.
“1” corresponds to maximum scrolling speed, “10” to minimum speed.
With “0” the message does not scroll and the display shows first 5 characters or the first 7 characters (on model 1250).
Unit of measurement: -
Options: 0...10 (default = 3)
Note: Descriptive messages of the parameters always flow at a constant speed.
