9. TECHNICAL DATA
OPERATOR INTERFACE 650 L 1250 L
DISPLAY
Type LCD black background
Screen area (L x H) 35×30 mm (1.38” x 1.18”) 37×68 mm (1.46” x 2.68”)
Lighting Backlit with LEDs, life > 40.000 hours @ 25 °C
* with brightness level BACKL=0.8
PV Display Number of digits: 4 to 7 segments, with decimal point
Digit height: 17 mm
Color: white or “custom”
SV Display Number of digits: 5 to 14 seg-
ments, with decimal point
Digit height: 7.5 mm (0.29”)
Color: green or “custom”
Number of digits: 4 to 7 seg-
ments, with decimal point
Digit height: 14 mm
Color: green or “custom”
F Display Number of digits: 5 to 14 seg-
ments, with decimal point
Digit height: 9 mm
Color: ambra or “custom”
Engineering units Selectable, °C, °F or custom
1
Color: same as PV display
Alarms state signals Number: 4 (1, 2, 3, 4)
Color: red
Bargraph indicator, configurable Type: graphic bargraph,11
segments
Deviation between AL1 and PV
KEYPAD
Keys number: 4, silicone ( R, INC,DEC,F)
Type: mechanical
1) Programming is done with the GF_eXpress configuration program.
