80224_MHW_650 L - 1250 L_07-2018_ENG - 44
4.5.9. HI.SCL - Upper limit of scale
Acronym Scrolling message Submenu Attributes
HI.SCL INPUT HIGH LIMIT I.MAIN R W
The parameter shows and sets the upper limit of the measurement scale used for the main input, based on input (or sen-
sor) type, engineering units, and number of decimals selected.
The lower value of HI.SCL is limited by the value of LO.SCL.
Unit of measurement: The one set with the Unit parameter
Options: A value in the interval corresponding to the input or sensor type (see tables for LO.SCL parameter).
4.5.10. OF.SCL - Scale offset correction
Acronym Scrolling message Submenu Attributes
OF.SCL INPUT OFFSET I.MAIN R W
The parameter shows and sets the offset applied to the value read in input to make it correspond to the expected value
for a certain temperature. It corrects any constant read error of the sensor.
This offset is applied linearly to all reads; therefore it cannot be used to correct any sensor linearity errors.
Unit of measurement: The one set with the Unit parameter
Options: -999...999
4.5.11. LO.AL - Lower limit for alarms
Acronym Scrolling message Submenu Attributes
LO.AL LOW LIMIT FOR ABSOLUTE ALARMS I.MAIN R W
The parameter shows and sets, the minimum value for setting an alarm.
Unit of measurement: The one used for the alarm limit.
Options: -1999...9999
4.5.12. HI.AL - Upper limit for alarms
Acronym Scrolling message Submenu Attributes
HI.AL HIGH LIMIT FOR ABSOLUTE ALARMS I.MAIN R W
The parameter shows and sets the upper limit for defining alarms, i.e., the maximum value for setting an alarm.
Unit of measurement: The one used for the alarm limit.
Options: -1999...9999
4. CONFIGURATION
