gefran 650 L User Manual

80224_MHW_650 L - 1250 L_07-2018_ENG - 43
4.5.6. FILT.D - Digital filter on PV display
Acronym Scrolling message Submenu Attributes
FILT.D DIGITAL FILTER ON DISPLAY PV I.MAIN R W
The parameter shows and sets the allowed tolerance between the real PV value and the value on the PV display: if the
variation in real PV is within the interval displayed value - FILT.D... displayed value + FILT.D the displayed value does not
change.
With 0.00 no filter is applied..
Unit of measurement: The one set with the Unit parameter
Options: 0.0...9.9
4.5.7. DEC.P - Number of decimals displayed
Acronym Scrolling message Submenu Attributes
DEC.P DECIMAL POINT POSITION I.MAIN R W
The parameter shows and sets the decimal point position for the process value (PV) displayed, i.e., defines its number of
decimal figures.
The number of decimal set may reduce the limits of the measurement scale used.
Unit of measurement: Number
Options: 0...3 = Number of decimals displayed
0 / 1 = Number of decimals displayed, only for TC and RTD sensors
4.5.8. LO.SCL - Lower limit of scale
Acronym Scrolling message Submenu Attributes
LO.SCL INPUT LOW LIMIT I.MAIN R W
The parameter shows and sets the lower limit of the measurement scale used for the main input, based on input (or sen-
sor) type, engineering units, and number of decimals selected.
The upper value of LO.SCL is not limited by the value of HI.SCL
Unit of measurement: The one set with the Unit parameter
Options: A numerical value within the temperature range of the input or sensor
Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
Unit = °C
DEC.P = 0
Unit = °F
DEC.P = 0
J.TC 0...1000 32...1832 JTP10 -200...600 -328...1112
K.TC 0...1300 32...2372 60MV -1999...9999 -1999...9999
R TC 0...1750 32...3182 20MA -1999...9999 -1999...9999
S TC 0...1750 32...3182 4-20M -1999...9999 -1999...9999
T.TC -200...400 -328...752 10V -1999...9999 -1999...9999
C.TC 0...2300 32...4172 2-10V -1999...9999 -1999...9999
D.TC 0...2300 32...4172 5V -1999...9999 -1999...9999
B 44…1800 111…3272 1-5V -1999...9999 -1999...9999
E -100…750 -148…1382 1V -1999...9999 -1999...9999
L -200...900 -328...1652 0.2-1V -1999...9999 -1999...9999
LGOST 0...600 32...1112 C.RTD -1999...9999 -1999...9999
U -200…400 -328…752 C.60MV -1999...9999 -1999...9999
G 0…2300 32…4172 C.20MA -1999...9999 -1999...9999
N 0…1300 32…2372 C.4-20 -1999...9999 -1999...9999
PT2.TC 0...1880 32...3416 C.10V -1999...9999 -1999...9999
INFR1 10...70 50...158 C.2-10 -1999...9999 -1999...9999
INFR2 60...120 140...248 C.5V -1999...9999 -1999...9999
INFR3 115...165 239...329 C.1-5V -1999...9999 -1999...9999
INFR4 140...260 284...500 C.1V -1999...9999 -1999...9999
PT100 -200...850 -328...1562 C.0.2-1 -1999...9999 -1999...9999
PT.LIM -50...250 -58...482
4. CONFIGURATION
