Honeywell APT4000PH User Manual

10
APT4000PH
40 60
132
1
2
3
4
5
Fig. 3: 51205988-001 pipe-mount kit
1 512005989-001 protective hood (if required)
2 Hose clamps with worm gear drive to DIN 3017 (2 pieces)
3 Pipe-mount plate (1 piece)
4 For vertical or horizontal posts or pipes
5 Self-tapping screws (4 pieces)
1
132165
173
1
Fig. 4: 51205989-001 protective hood for wall and
pipe mounting
Pipe mounting, panel mounting
All dimensions in mm.
11
1
2
3
45
max. 25
78 27
1...22
1 Screws (4 pieces)
2 Gasket (1 piece)
3 Control panel
4 Span pieces (4 pieces)
5 Threaded sleeves (4 pieces)
Fig. 5: 51205990-001 panel-mount kit
All dimensions in mm.
