Solaris 7980g User Guide 141
Data Matrix Code Page
Data Matrix Code pages define the mapping of character codes to characters. If the
data received does not display with the proper characters, it may be because the
bar code being scanned was created using a code page that is different from the
one the host program is expecting. If this is the case, scan the bar code below,
select the code page with which the bar codes were created (see ISO 2022/ISO 646
Character Replacements on page 228), and scan the value and the Save bar code
from the Programming Chart. The data characters should then appear properly.
MaxiCode
< Default All MaxiCode Settings >
MaxiCode On/Off
MaxiCode Message Length
Scan the bar codes below to change the message length. Refer to Message Length
Description (page 92) for additional information. Minimum and Maximum lengths
= 1-150. Minimum Default = 1, Maximum Default = 150.
To Next Page
