Solaris 7980g User Guide 79
The data is output as: Code128 20 1234567890ABCDEFGHIJ
<CR>
Insert key strokes
B5 Insert a key stroke or combination of key strokes. Key strokes are dependent on your
keyboard (see Keyboard Key References on page 231). Any key can be inserted,
including arrows and functions. Syntax = B5xxssnn where xx is the number of keys
pressed (without key modifiers), ss is the key modifier from the table below, and nn
is the key number from the Keyboard Key References, page 231.
For example, B501021F inserts an “A” on a 104 key, U.S. style keyboard. B5 = the
command, 01 = number of keys pressed (without the key modifier), 02 is the key
modifier for Shift Right, and 1F is the “a” key. If a lower case “a” were to be inserted,
B501001F would be entered.
If there are three keystrokes, the syntax would change from B5xxssnn for one key-
stroke to B5xxssnnssnnssnn. An example that would insert "abc" is as follows:
B503001F00320030F833.
Note: Key modifiers can be added together when needed. Example: Control Left+Shift Left
= 11.
Move Commands
Move the cursor forward a number of characters
F5 Move the cursor ahead “nn” characters from current cursor position. Syntax = F5nn
where nn is the numeric value (00-99) for the number of characters the cursor
should be moved ahead.
F5 Example: Move the cursor forward and send the data
Move the cursor forward 3 characters, then send the rest of the bar code data from
the bar code above. End with a carriage return.
Command string: F503F10D
Key Modifiers
No Key Modifier 00
Shift Left 01
Shift Right 02
Alt Left 04
Alt Right 08
Control Left 10
Control Right 20
