Plotting to an HP LaserJet Printer
This section describes how to plot to a LaserJet printer using either an RS-232 or parallel
interface.
Equipment
n HP 8590 Series spectrum analyzer with RS-232 or parallel interface
n One of the following cables:
q HP 24542G 9-25 pin RS-232 cable
q HP C2932A 9-25 Pin RS-232 Cable (For use with LaserJet 4P and 4Plus)
q HP C2950A parallel printer cable
n Any of the following HP LaserJets:
q HP LaserJet IIP Plus
q HP LaserJet III
q HP LaserJet IIIP
q HP LaserJet 4
q HP LaserJet 4L
q HP LaserJet 4P
Interconnection and Plotting Instructions
The RS-232 or parallel interface allow only one device to be connected to the spectrum
analyzer. Refer to the programmer’s guide for more information on protocol and cable wiring.
1. Turn off the spectrum analyzer and LaserJet.
2. Connect the HP LaserJet to the analyzer.
3. Turn on the analyzer and the HP LaserJet printer.
Printing and Plotting 6-21
