HP dc5100 - Microtower PC Service & Reference Guide

Service Reference Guide, dc5100 376220-001 6–13
Removal and Replacement Procedures— Microtower (MT) Chassis
6.8.1 Cable Connections
Cable To Cable Designator
Power Supply System board P1
Power Supply 1st SATA Hard drive P10
Power Supply System board P7
Power Supply 1st Optical drive P2
Power Supply 2nd Optical drive P3
Power Supply 2nd SATA Hard drive P9
Power Supply DIskette drive P8
Cable To PCA Designator
Diskette drive System board P10 (Black)
1st SATA Hard drive System board P60 (SATA 0 Dark blue)
2nd SATA Hard drive System board P61 (SATA 1 White)
ODD Data System board P20 (Blue)
ODD Audio System board P7 (CD )
2nd ODD Audio System board P11 (AUX)
Heatsink fan System board P70
Secondary system fan System board P3 (Red)
Front power on button System board P5
Front I/O USB System board P24 (Yellow)
Front I/O Audio System board P23 (Black)
Speaker System board P6 (White)
Serial port connector System board P52
