HP DL360 Reference And Troubleshooting Guide

Server Component Identification 13
Item Description Item Description
7 SCSI backplane
connector*
15 PCI riser board assembly
connector (for slot 1 riser
board)
8 Optical device connector 16 System battery
* For SCSI models only
System Maintenance Switch
Position Default Function
S1 Off Off = iLO security is enabled.
On = iLO security is disabled.
S2 Off Off = System configuration can be
changed.
On = System configuration is
locked.
S3 Off Reserved
S4 Off Reserved
S5 Off Off = Power-on password is
enabled.
On = Power-on password is
disabled.
S6 Off Off = No function
On = ROM treats the system
configuration as invalid.
S7, S8 Off, Off Debug LEDs
