38 HP ProLiant DL360 Generation 4 Server Reference and Troubleshooting Guide
Installing the Server into the Rack
To install the server into a rack with square, round, or threaded holes, refer to the
instructions that ship with the rack hardware kit.
If you are installing the server into a telco rack, order the appropriate option kit at
the RackSolutions.com website (http://www.racksolutions.com/hp
). Follow the
server-specific instructions on the website to install the rack brackets.
Use the information below when connecting peripheral cables and power cords to
the server.
WARNING: To reduce the risk of electric shock, fire, or
damage to the equipment, do not plug telephone or
telecommunications connectors into RJ-45 connectors.
Item Description
1 PCI-X expansion slot 1, 64-bit/133-MHz 3.3V
(optional PCI Express slot 1, x8)
2 PCI-X expansion slot 2, 64-bit/133-MHz 3.3V
(optional PCI Express slot 2, x8)
3 Power supply bay 2
