48
Chapter 2: Installing the Emulation Module
Installing into a Logic Analysis System
Installing into a Logic Analysis System
Your emulation module may already be installed in your logic analysis
system. However, if you need to install an emulation module, follow the
instructions on the pages which follow.
CAUTION: These instructions are for trained service personnel. To avoid dangerous
electric shock, do not perform any service unless qualified to do so. Do not
attempt internal service or adjustment unless another person, capable of
rendering first aid and resuscitation, is present.
Electrostatic discharge can damage electronic components. Use grounded
wrist straps and mats when you handle modules.
To install in a HP 16700A-series logic analysis
system
Or, to install in an HP 16701A expansion frame:
You will need a T-10 Torx screw driver.
1 Turn off the logic analysis system and REMOVE THE POWER
CORD.
Remove any other cables (including mouse or video monitor cables).
2 Turn the logic analysis system frame upside-down.
3 Remove the bottom cover.
