55
Chapter 2: Installing the Emulation Module
Installing Software
NOTE: If the CD-ROM drive is not connected, see the instructions printed on the
CD-ROM package.
1 Turn on the CD-ROM drive first; then, turn on the logic analysis
system.
2 Insert the CD-ROM in the drive.
3 Click the System Admin icon.
4 Click Install... .
5 Select CD-ROM as the media, and click Apply.
6 From the list of types of packages, double-click “PROC-
SUPPORT.”
A list of the processor support packages on the CD-ROM will be
displayed.
7 Click on the “MPC5XX” package.
If you are unsure if this is the correct package, click Details for
information on what the package contains.
8 Click Install... .
The dialog box will display “Progress: completed successfully” when
the installation is complete.
9 Click Close.
The firmware is stored in /hplogic/run_control/firmware.
See Also The on-line help for more information on installing, licensing, and
removing software.
