Table 2-10 Action keys and their descriptions

Icon Description

Switches the screen image among display devices connected to the system. For example, if a monitor is

connected to the computer, repeatedly pressing the key alternates the screen image from computer display

to monitor display to simultaneous display on both the computer and the monitor.

Helps prevent side-angle viewing from onlookers. If needed, decrease or increase brightness for well-lit or

darker environments. Press the key again to turn o the privacy screen.

NOTE: This feature is available only on select products. If the feature is not available on your computer, a

message is displayed when you press this key.

NOTE: To quickly turn on the highest privacy setting, press fn+p.

Decreases the screen brightness incrementally as long as you hold down the key.

Increases the screen brightness incrementally as long as you hold down the key.

Mutes or restores speaker sound.

Decreases speaker volume incrementally while you hold down the key.

Increases speaker volume incrementally while you hold down the key.

Mutes the microphone.

Turns the keyboard backlight o or on. On select products, you can adjust the brightness of the keyboard

backlight. Press the key repeatedly to adjust the brightness from high (when you rst start up the computer),

to low, to o. After you adjust the keyboard backlight setting, the backlight will revert to your previous

setting each time you turn on the computer. The keyboard backlight will turn o after 30 seconds of

inactivity. To turn the keyboard backlight back on, press any key or tap the touchpad (select products only). To

conserve battery power, turn o this feature.

Turns the wireless feature on or o.

NOTE: A wireless network must be set up before a wireless connection is possible.

Executes frequently used tasks. Some tasks might not be available on all products.

● Opens an application, le, or website

● Enters frequently used text into a permanent clipboard

18 Chapter 2 Components

Questions and Answers:

Need help?

Do you have a question about the HP Elite x2 G8 and is the answer not in the manual?

HP Elite x2 G8 Specifications

General

Form factor	Convertible (Detachable)
Product type	Hybrid (2-in-1)
Product color	Silver
Country of origin	China
Market positioning	Premium
Original brand name	HP
HD type	3K2K
Color gamut	72 %
Display surface	Gloss
RGB color space	NTSC
Display diagonal	13 \
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Display brightness	450 cd/m²
Display resolution	3000 x 2000 pixels
Display diagonal (metric)	33 cm
Numeric keypad	No
Pointing device	Clickpad
Internal memory	16 GB
Memory clock speed	4266 MHz
Memory form factor	On-board
Internal memory type	LPDDR4x-SDRAM
HP segment	Business
HP speaker type	HP Dual Speakers
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
SSD interface	NVMe, PCI Express
Storage media	SSD
SSD memory type	TLC
Total storage capacity	512 GB
Number of SSDs installed	1
Repairability index	8.4
Battery weight	190 g
Battery capacity	47 Wh
Number of battery cells	2
Discrete graphics card model	Not available
On-board graphics card model	Intel Iris Xe Graphics
Front camera HD type	Full HD
Antenna type	2x2
Wi-Fi standards	Wi-Fi 6 (802.11ax)
Bluetooth version	5.0
WLAN controller model	Intel Wi-Fi 6 AX201
WLAN controller manufacturer	Intel
Charging port type	USB Type-C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
Processor cache	8 MB
Processor cores	4
Processor family	Intel® Core™ i5
Processor threads	8
Configurable TDP-up	28 W
Processor frequency	- GHz
Processor cache type	L3
Configurable TDP-down	12 W
Processor boost frequency	4.4 GHz
Configurable TDP-up frequency	2.6 GHz
Configurable TDP-down frequency	1.1 GHz
AC adapter power	65 W
Operating system installed	Windows 11 Pro
Package depth	483 mm
Package width	69 mm
Package height	305 mm
